Cummins
Cummins KTA38-G2
K38 Series
The Cummins KTA38-G2 is a 38-litre V12 diesel engine for generator sets, rated at 825 kVA / 660 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Chat on WhatsApp about this engine
Opens WhatsApp with Cummins KTA38-G2 and this page link filled in.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 825 kVA
- Electrical Output
- 660 kWe
- Cylinders
- V12
- Displacement
- 38 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 666.7 | 600 | 750 |
| Standby Power | 733.3 | 660 | 825 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 805.6 | 725 | 906.3 |
| Standby Power | 888.9 | 800 | 1000 |
Cummins KTA38-G2 generator set context
The Cummins KTA38-G2 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 825 kVA / 660 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | KTA38-G2 |
| Series | K38 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 38 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins KTA38-G2?
The Cummins KTA38-G2 is rated at 825 kVA standby / 750 kVA prime at 50 Hz (1,500 rpm); and 1,000 kVA standby / 906 kVA prime at 60 Hz (1,800 rpm).
Does the KTA38-G2 run at 50 Hz or 60 Hz?
The Cummins KTA38-G2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Cummins KTA38-G2 use?
The Cummins KTA38-G2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KTA38-G2?
The Cummins KTA38-G2 is a V12 (12-cylinder) engine with a displacement of 38 L.
Is the Cummins KTA38-G2 still in production?
Yes — the Cummins KTA38-G2 is a current production model.
Is a datasheet available for the KTA38-G2?
Yes — an official Cummins datasheet for the Cummins KTA38-G2 can be downloaded from this page.
