Cummins
Cummins KTA50-G9
K50 Series
The Cummins KTA50-G9 is a 50.3-litre V16 diesel engine for generator sets, rated at 1,875 kVA / 1,500 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
Chat on WhatsApp about this engine
Opens WhatsApp with Cummins KTA50-G9 and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 1,875 kVA
- Electrical Output
- 1,500 kWe
- Cylinders
- V16
- Displacement
- 50.3 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1400 | 1260 | 1575 |
| Standby Power | 1666.7 | 1500 | 1875 |
Cummins KTA50-G9 generator set context
The Cummins KTA50-G9 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 1,875 kVA / 1,500 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | KTA50-G9 |
| Series | K50 Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 50.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Cummins KTA50-G9?
The Cummins KTA50-G9 is rated at 1,875 kVA standby / 1,575 kVA prime at 60 Hz (1,800 rpm).
Does the KTA50-G9 run at 50 Hz or 60 Hz?
The Cummins KTA50-G9 is rated for 60 Hz (1,800 rpm).
What fuel does the Cummins KTA50-G9 use?
The Cummins KTA50-G9 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KTA50-G9?
The Cummins KTA50-G9 is a V16 (16-cylinder) engine with a displacement of 50.3 L.
Is the Cummins KTA50-G9 still in production?
Yes — the Cummins KTA50-G9 is a current production model.
Is a datasheet available for the KTA50-G9?
Yes — an official Cummins datasheet for the Cummins KTA50-G9 can be downloaded from this page.
