Cummins
Cummins KTA50G20
KTA Series
Cummins KTA50G20 generator-drive diesel engine discovered in the GenProBase public selector. GenProBase lists 2 row(s) across 50Hz, 60Hz with 50 L displacement, 16V cylinders, liquid-cooled cooling, and Unregulated emissions labeling. Treat this row as source-discovered and prioritize OEM datasheet attachment in a follow-up pass.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-08-05
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,395 kVA
- Electrical Output
- 1,116 kWe
- Cylinders
- V16
- Displacement
- 50 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1095 | 1020 | — |
| Standby Power | 1210 | 1116 | — |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1178 | 1085 | — |
| Standby Power | 1306 | 1195 | — |
Ask about Cummins KTA50G20
Choose parts / service or sourcing. Your message includes this model and page link.
Cummins KTA50G20 overhaul & repair parts
Already running a Cummins KTA50G20? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with KTA50G20 and your selected categories included. Attach your photos there.
Cummins KTA50G20 generator set context
The Cummins KTA50G20 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,395 kVA / 1,116 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Cummins |
| Model | KTA50G20 |
| Series | KTA Series |
| Configuration | L16, turbocharged aftercooled |
| Cylinders | 16 |
| Displacement | 50 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | India |
Frequently asked questions
What is the power output of the Cummins KTA50G20?
The Cummins KTA50G20 is rated at 1,395 kVA standby / 1,275 kVA prime at 50 Hz (1,500 rpm); and 1,494 kVA standby / 1,356 kVA prime at 60 Hz (1,800 rpm).
Does the KTA50G20 run at 50 Hz or 60 Hz?
The Cummins KTA50G20 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Cummins KTA50G20 use?
The Cummins KTA50G20 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the KTA50G20?
The Cummins KTA50G20 is a V16 (16-cylinder) engine with a displacement of 50 L.
What is the catalog status of the Cummins KTA50G20?
The Cummins KTA50G20 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
