Doosan
Doosan P086TI-1
P Series
Doosan P086TI-1 P Series diesel engine. Legacy Doosan generator-drive diesel for standby and prime generator sets.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-08-04
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 185 kVA
- Electrical Output
- 148 kWe
- Cylinders
- L6
- Displacement
- 8.071 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 149 | 134.1 | 167.6 |
| Standby Power | 164 | 147.6 | 184.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 174 | 156.6 | 195.7 |
| Standby Power | 191 | 171.9 | 214.9 |
Ask about Doosan P086TI-1
Choose parts / service or sourcing. Your message includes this model and page link.
Doosan P086TI-1 overhaul & repair parts
Already running a Doosan P086TI-1? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with P086TI-1 and your selected categories included. Attach your photos there.
Doosan P086TI-1 generator set context
The Doosan P086TI-1 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 185 kVA / 148 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Doosan |
| Model | P086TI-1 |
| Series | P Series |
| Configuration | L6, turbocharged intercooled |
| Cylinders | 6 |
| Displacement | 8.071 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Doosan P086TI-1?
The Doosan P086TI-1 is rated at 185 kVA standby / 168 kVA prime at 50 Hz (1,500 rpm); and 215 kVA standby / 196 kVA prime at 60 Hz (1,800 rpm).
Does the P086TI-1 run at 50 Hz or 60 Hz?
The Doosan P086TI-1 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Doosan P086TI-1 use?
The Doosan P086TI-1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the P086TI-1?
The Doosan P086TI-1 is an inline-6 (6-cylinder) engine with a displacement of 8.071 L.
Is the P086TI-1 still in production?
No — the Doosan P086TI-1 is discontinued. Its specifications and datasheets remain archived here for reference.
