Googol
Googol PTAA12V-EG815
P Series
The Googol PTAA12V-EG815 is a 24.4-litre V12 diesel engine for generator sets, rated at 880 kVA / 704 kWe standby power at 1,500 RPM (50 Hz). It is a air-air-cooled engine built in China.
- Standby Power · 50 Hz
- 880 kVA
- Electrical Output
- 704 kWe
- Cylinders
- V12
- Displacement
- 24.4 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 711.1 | 640 | 800 |
| Standby Power | 782.2 | 704 | 880 |
Technical Specifications
| Brand | Googol |
| Model | PTAA12V-EG815 |
| Series | P Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 24.4 L |
| Dry Weight | 1650 kg |
| Dimensions (L×W×H) | 1905 × 1403 × 1427 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Air-Air |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Googol PTAA12V-EG815?
The Googol PTAA12V-EG815 is rated at 880 kVA standby / 800 kVA prime at 50 Hz (1,500 rpm).
Does the PTAA12V-EG815 run at 50 Hz or 60 Hz?
The Googol PTAA12V-EG815 is rated for 50 Hz (1,500 rpm).
What fuel does the Googol PTAA12V-EG815 use?
The Googol PTAA12V-EG815 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the PTAA12V-EG815?
The Googol PTAA12V-EG815 is a V12 (12-cylinder) engine with a displacement of 24.4 L.
Is the Googol PTAA12V-EG815 still in production?
Yes — the Googol PTAA12V-EG815 is a current production model.
Is a datasheet available for the PTAA12V-EG815?
Yes — an official Googol datasheet for the Googol PTAA12V-EG815 can be downloaded from this page.
