Googol
Googol PTAA16V-EG1225
P Series
The Googol PTAA16V-EG1225 is a 32.5-litre V16 diesel engine for generator sets, rated at 1,375 kVA / 1,100 kWe standby power at 1,500 RPM (50 Hz). It is a air-air-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Googol PTAA16V-EG1225 engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-07
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,375 kVA
- Electrical Output
- 1,100 kWe
- Cylinders
- V16
- Displacement
- 32.5 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1111.1 | 1000 | 1250 |
| Standby Power | 1222.2 | 1100 | 1375 |
Googol PTAA16V-EG1225 generator set context
The Googol PTAA16V-EG1225 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,375 kVA / 1,100 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Googol |
| Model | PTAA16V-EG1225 |
| Series | P Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 32.5 L |
| Dry Weight | 2050 kg |
| Dimensions (L×W×H) | 2186 × 1156 × 1426 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Air-Air |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Googol PTAA16V-EG1225?
The Googol PTAA16V-EG1225 is rated at 1,375 kVA standby / 1,250 kVA prime at 50 Hz (1,500 rpm).
Does the PTAA16V-EG1225 run at 50 Hz or 60 Hz?
The Googol PTAA16V-EG1225 is rated for 50 Hz (1,500 rpm).
What fuel does the Googol PTAA16V-EG1225 use?
The Googol PTAA16V-EG1225 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the PTAA16V-EG1225?
The Googol PTAA16V-EG1225 is a V16 (16-cylinder) engine with a displacement of 32.5 L.
Is the Googol PTAA16V-EG1225 still in production?
Yes — the Googol PTAA16V-EG1225 is a current production model.
Is a datasheet available for the PTAA16V-EG1225?
Yes — an official Googol datasheet for the Googol PTAA16V-EG1225 can be downloaded from this page.
