Googol
Googol QTA16V-EG2220D
Q Series
The Googol QTA16V-EG2220D is a 86-litre V16 diesel engine for generator sets, rated at 2,500 kVA / 2,000 kWe standby power at 1,500 RPM (50 Hz). It is a water-air-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Googol QTA16V-EG2220D engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-07
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,500 kVA
- Electrical Output
- 2,000 kWe
- Cylinders
- V16
- Displacement
- 86 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2000 | 1800 | 2250 |
| Standby Power | 2222.2 | 2000 | 2500 |
Googol QTA16V-EG2220D generator set context
The Googol QTA16V-EG2220D is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,500 kVA / 2,000 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Googol |
| Model | QTA16V-EG2220D |
| Series | Q Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 86 L |
| Dry Weight | 6400 kg |
| Dimensions (L×W×H) | 3670 × 1634 × 2130 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Water-Air |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Googol QTA16V-EG2220D?
The Googol QTA16V-EG2220D is rated at 2,500 kVA standby / 2,250 kVA prime at 50 Hz (1,500 rpm).
Does the QTA16V-EG2220D run at 50 Hz or 60 Hz?
The Googol QTA16V-EG2220D is rated for 50 Hz (1,500 rpm).
What fuel does the Googol QTA16V-EG2220D use?
The Googol QTA16V-EG2220D is a diesel generator-set engine.
What is the displacement and cylinder configuration of the QTA16V-EG2220D?
The Googol QTA16V-EG2220D is a V16 (16-cylinder) engine with a displacement of 86 L.
Is the Googol QTA16V-EG2220D still in production?
Yes — the Googol QTA16V-EG2220D is a current production model.
Is a datasheet available for the QTA16V-EG2220D?
Yes — an official Googol datasheet for the Googol QTA16V-EG2220D can be downloaded from this page.
