Hatz
Hatz 4H50TICD
H50 Series
Hatz 4H50TICD 1.952 L inline-4 diesel engine with cooled EGR, DOC and DPF aftertreatment. The official Hatz H-Series datasheet publishes constant-speed ISO fuel-stop output of 35.0 kWm at 1500 RPM and 41.0 kWm at 1800 RPM. EPA certification data lists the model at 1800 RPM under Tier 4 Final.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-24
- Package route
- diesel generator sets
- Mechanical Output
- 35 kW
- Cylinders
- L4
- Displacement
- 1.952 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 35 | — | — |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 41 | — | — |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Hatz 4H50TICD
Choose parts / service or sourcing. Your message includes this model and page link.
Hatz 4H50TICD overhaul & repair parts
Already running a Hatz 4H50TICD? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 4H50TICD and your selected categories included. Attach your photos there.
Hatz 4H50TICD generator set context
The Hatz 4H50TICD is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 35 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hatz |
| Model | 4H50TICD |
| Series | H50 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 1.952 L |
| Compression Ratio | 17.5:1 |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V / U.S. EPA Final Tier 4 |
| Certifications | EU Stage V, U.S. EPA Tier 4 Final |
| Country of Origin | Germany |
| Year Introduced | 2020 |
Frequently asked questions
Does the 4H50TICD run at 50 Hz or 60 Hz?
The Hatz 4H50TICD is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hatz 4H50TICD use?
The Hatz 4H50TICD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4H50TICD?
The Hatz 4H50TICD is an inline-4 (4-cylinder) engine with a displacement of 1.952 L.
What emissions information is listed for the 4H50TICD?
This record lists Euro Stage V / U.S. EPA Final Tier 4 for the Hatz 4H50TICD. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Hatz 4H50TICD?
The Hatz 4H50TICD is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4H50TICD?
This page links reference documents for the Hatz 4H50TICD. Check each document's title, model coverage, revision and rating conditions before using it for selection.
