Hino
Hino J05E
J Series
Hino J05E 5.1L 4-cylinder diesel engine for generator sets. ~44 kWe standby at 50Hz (representative rating). Unregulated. Turbocharged Intercooled.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 55 kVA
- Electrical Output
- 44 kWe
- Cylinders
- L4
- Displacement
- 5.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 44 | 39.6 | 49.5 |
| Standby Power | 48.9 | 44 | 55 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 52.8 | 47.5 | 59.4 |
| Standby Power | 58.7 | 52.8 | 66 |
Ask about Hino J05E
Choose parts / service or sourcing. Your message includes this model and page link.
Hino J05E overhaul & repair parts
Already running a Hino J05E? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with J05E and your selected categories included. Attach your photos there.
Hino J05E generator set context
The Hino J05E is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 55 kVA / 44 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hino |
| Model | J05E |
| Series | J Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 5.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Hino J05E?
The Hino J05E is rated at 55 kVA standby / 50 kVA prime at 50 Hz (1,500 rpm); and 66 kVA standby / 59 kVA prime at 60 Hz (1,800 rpm).
Does the J05E run at 50 Hz or 60 Hz?
The Hino J05E is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hino J05E use?
The Hino J05E is a diesel generator-set engine.
What is the displacement and cylinder configuration of the J05E?
The Hino J05E is an inline-4 (4-cylinder) engine with a displacement of 5.1 L.
What is the catalog status of the Hino J05E?
The Hino J05E is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
