Hino
Hino J08E
J Series
Hino J08E 7.7L 6-cylinder diesel engine for generator sets. ~104 kWe standby at 50Hz (representative rating). Unregulated. Turbocharged Intercooled.
- Standby Power · 50 Hz
- 130 kVA
- Electrical Output
- 104 kWe
- Cylinders
- L6
- Displacement
- 7.7 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 104 | 93.6 | 117 |
| Standby Power | 115.6 | 104 | 130 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 124.8 | 112.3 | 140.4 |
| Standby Power | 138.7 | 124.8 | 156 |
Hino J08E generator set context
The Hino J08E is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 130 kVA / 104 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hino |
| Model | J08E |
| Series | J Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.7 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Hino J08E?
The Hino J08E is rated at 130 kVA standby / 117 kVA prime at 50 Hz (1,500 rpm); and 156 kVA standby / 140 kVA prime at 60 Hz (1,800 rpm).
Does the J08E run at 50 Hz or 60 Hz?
The Hino J08E is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hino J08E use?
The Hino J08E is a diesel generator-set engine.
What is the displacement and cylinder configuration of the J08E?
The Hino J08E is an inline-6 (6-cylinder) engine with a displacement of 7.7 L.
Is the Hino J08E still in production?
Yes — the Hino J08E is a current production model.
Is a datasheet available for the J08E?
Yes — an official Hino datasheet for the Hino J08E can be downloaded from this page.
Compare Hino J08E
Reference
- Canonical page
- /engines/hino-j08e
- Last database update
- 2026-06-11
- Manufacturer files
- 1 datasheet linked
