Hyundai
Hyundai DP158CAK
DP158 Series
Hyundai DP158CAK is a 15.1L L6 6-cylinder diesel generator-drive engine in the DP158 Series, rated at 418 kWe standby output at 1,500 rpm / 50 Hz. It is U.S. EPA Tier 2 emissions and built in South Korea.
Overhaul & repair parts- Supporting documents
- 4 documents · 2 datasheets
- Last updated
- 2026-06-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 523 kVA
- Electrical Output
- 418 kWe
- Cylinders
- L6
- Displacement
- 15.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 420 | 378 | 472.5 |
| Standby Power | 464.4 | 418 | 522.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 470 | 423 | 528.8 |
| Standby Power | 520 | 468 | 585 |
Ask about Hyundai DP158CAK
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai DP158CAK overhaul & repair parts
Already running a Hyundai DP158CAK? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DP158CAK and your selected categories included. Attach your photos there.
Hyundai DP158CAK generator set context
The Hyundai DP158CAK is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 523 kVA / 418 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP158CAK |
| Series | DP158 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 15.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP158CAK?
The Hyundai DP158CAK is rated at 523 kVA standby / 473 kVA prime at 50 Hz (1,500 rpm); and 585 kVA standby / 529 kVA prime at 60 Hz (1,800 rpm).
Does the DP158CAK run at 50 Hz or 60 Hz?
The Hyundai DP158CAK is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP158CAK use?
The Hyundai DP158CAK is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP158CAK?
The Hyundai DP158CAK is an inline-6 (6-cylinder) engine with a displacement of 15.1 L.
What emissions information is listed for the DP158CAK?
This record lists U.S. EPA Tier 2 for the Hyundai DP158CAK. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Hyundai DP158CAK?
The Hyundai DP158CAK is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DP158CAK?
This page links reference documents for the Hyundai DP158CAK. Check each document's title, model coverage, revision and rating conditions before using it for selection.
