Hyundai
Hyundai DP023CAV
DP023 Series
Hyundai DP023CAV 1.8L 3-cylinder diesel engine for generator sets. Euro Stage V certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP023CAV and this page link filled in.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 33 kVA
- Electrical Output
- 26 kWe
- Cylinders
- L3
- Displacement
- 1.8 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 26.7 | 24 | 30 |
| Standby Power | 28.9 | 26 | 32.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 37.8 | 34 | 42.5 |
| Standby Power | 41.1 | 37 | 46.3 |
Hyundai DP023CAV generator set context
The Hyundai DP023CAV is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 33 kVA / 26 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP023CAV |
| Series | DP023 Series |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP023CAV?
The Hyundai DP023CAV is rated at 33 kVA standby / 30 kVA prime at 50 Hz (1,500 rpm); and 46 kVA standby / 43 kVA prime at 60 Hz (1,800 rpm).
Does the DP023CAV run at 50 Hz or 60 Hz?
The Hyundai DP023CAV is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP023CAV use?
The Hyundai DP023CAV is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP023CAV?
The Hyundai DP023CAV is an inline-3 (3-cylinder) engine with a displacement of 1.8 L.
What emissions standard does the DP023CAV meet?
The Hyundai DP023CAV is certified to Euro Stage V emissions standards.
Is the Hyundai DP023CAV still in production?
Yes — the Hyundai DP023CAV is a current production model.
Is a datasheet available for the DP023CAV?
Yes — an official Hyundai datasheet for the Hyundai DP023CAV can be downloaded from this page.
