Isuzu
Isuzu 4LE2T
4L-Series
Isuzu 4LE2T 2.179L 4-cylinder diesel engine for generator sets. 30 kW prime at 60Hz. U.S. EPA Final Tier 4. Turbocharged.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 31 kVA
- Electrical Output
- 25 kWe
- Cylinders
- L4
- Displacement
- 2.179 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 25 | 22.5 | 28.1 |
| Standby Power | 27.5 | 24.8 | 31 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 30 | 27 | 33.8 |
| Standby Power | 33 | 29.7 | 37.1 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Isuzu 4LE2T
Choose parts / service or sourcing. Your message includes this model and page link.
Isuzu 4LE2T overhaul & repair parts
Already running a Isuzu 4LE2T? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 4LE2T and your selected categories included. Attach your photos there.
Isuzu 4LE2T generator set context
The Isuzu 4LE2T is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 31 kVA / 25 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Isuzu |
| Model | 4LE2T |
| Series | 4L-Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.179 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Isuzu 4LE2T?
The Isuzu 4LE2T is rated at 31 kVA standby / 28 kVA prime at 50 Hz (1,500 rpm); and 37 kVA standby / 34 kVA prime at 60 Hz (1,800 rpm).
Does the 4LE2T run at 50 Hz or 60 Hz?
The Isuzu 4LE2T is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Isuzu 4LE2T use?
The Isuzu 4LE2T is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4LE2T?
The Isuzu 4LE2T is an inline-4 (4-cylinder) engine with a displacement of 2.179 L.
What emissions information is listed for the 4LE2T?
This record lists U.S. EPA Final Tier 4 for the Isuzu 4LE2T. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Isuzu 4LE2T?
The Isuzu 4LE2T is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4LE2T?
This page links reference documents for the Isuzu 4LE2T. Check each document's title, model coverage, revision and rating conditions before using it for selection.
