Jichai
Jichai AH12V190ZLD
190 series
Jichai AH12V190ZLD — 73.16 L V12 (190 × 215 mm) ECU common-rail turbocharged diesel generator engine (CNPC Jichai H12V190 series). 1740 kW engine / 1500 kWe genset (400 V–10.5 kV) at 1500 rpm, GB20891 Stage III, ≤202 g/kWh.
- Prime Power · 50 Hz
- 1,875 kVA
- Electrical Output
- 1,500 kWe
- Cylinders
- V12
- Displacement
- 73.16 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1500 | 1875 |
Jichai AH12V190ZLD generator set context
The Jichai AH12V190ZLD is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,875 kVA / 1,500 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | AH12V190ZLD |
| Series | 190 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 73.16 L |
| Compression Ratio | 14:1 |
| Dry Weight | 9300 kg |
| Dimensions (L×W×H) | 2950 × 1980 × 2206 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai AH12V190ZLD?
The Jichai AH12V190ZLD is rated at 1,875 kVA prime at 50 Hz (1,500 rpm).
Does the AH12V190ZLD run at 50 Hz or 60 Hz?
The Jichai AH12V190ZLD is rated for 50 Hz (1,500 rpm).
What fuel does the Jichai AH12V190ZLD use?
The Jichai AH12V190ZLD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the AH12V190ZLD?
The Jichai AH12V190ZLD is a V12 (12-cylinder) engine with a displacement of 73.16 L.
What emissions standard does the AH12V190ZLD meet?
The Jichai AH12V190ZLD is certified to China III (GB20891) emissions standards.
Is the Jichai AH12V190ZLD still in production?
Yes — the Jichai AH12V190ZLD is a current production model.
