Jichai AH16V190ZLD1 — 97.53 L V16 (190 × 215 mm) high-boost turbocharged diesel generator engine (CNPC Jichai H16V190 series). 2400 kW engine / 2200 kWe genset (400 V–10.5 kV) at 1500 rpm, GB20891 Stage III, ≤205 g/kWh.
Production StatusIn Production
190 series
- Configuration
- V16
- Displacement
- 97.53 L
- Fuel
- Diesel
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| Rating | Prime |
|---|---|
| Electrical output kWe | 2,200 |
| Apparent power kVA | 2,750 |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Jichai |
| Model | AH16V190ZLD1 |
| Series | 190 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 97.53 L |
| Compression Ratio | 14:1 |
| Dry Weight | 13000 kg |
| Dimensions (L×W×H) | 3510 × 3036 × 2344 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
Check your engine model
The Jichai AH16V190ZLD1 is a diesel generator-drive engine for 50 Hz generator sets, rated at 2,750 kVA / 2,200 kWe / prime rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
ah16v190zld1Jichai AH16V190ZLD1190 series AH16V190ZLD1
AH16V190ZLD1 repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Parts reference availability
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
What is the power output of the Jichai AH16V190ZLD1?
The Jichai AH16V190ZLD1 is rated at 2,750 kVA prime at 50 Hz (1,500 rpm).
Does the AH16V190ZLD1 run at 50 Hz or 60 Hz?
The Jichai AH16V190ZLD1 is rated for 50 Hz (1,500 rpm).
What fuel does the Jichai AH16V190ZLD1 use?
The Jichai AH16V190ZLD1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the AH16V190ZLD1?
The Jichai AH16V190ZLD1 is a V16 (16-cylinder) engine with a displacement of 97.53 L.
What emissions information is listed for the AH16V190ZLD1?
This record lists China III (GB20891) for the Jichai AH16V190ZLD1. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Jichai AH16V190ZLD1?
The Jichai AH16V190ZLD1 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
