Jichai
Jichai G12V190ZLD3
190 series
Jichai G12V190ZLD3 — 71.45 L V12 (190 × 210 mm) common-rail turbocharged diesel generator engine (CNPC Jichai G12V190 series, upgraded from the Z12V190). 1000 kW engine / 800 kWe genset (400 V–10.5 kV) at 1500 rpm, GB20891 Stage III, ≤205 g/kWh.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-29
- Package route
- diesel generator sets
- Prime Power · 50 Hz
- 1,000 kVA
- Electrical Output
- 800 kWe
- Cylinders
- V12
- Displacement
- 71.45 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 800 | 1000 |
Ask about Jichai G12V190ZLD3
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai G12V190ZLD3 overhaul & repair parts
Already running a Jichai G12V190ZLD3? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with G12V190ZLD3 and your selected categories included. Attach your photos there.
Jichai G12V190ZLD3 generator set context
The Jichai G12V190ZLD3 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,000 kVA / 800 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | G12V190ZLD3 |
| Series | 190 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 71.45 L |
| Compression Ratio | 14:1 |
| Dry Weight | 5300 kg |
| Dimensions (L×W×H) | 2688 × 1665 × 2118 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai G12V190ZLD3?
The Jichai G12V190ZLD3 is rated at 1,000 kVA prime at 50 Hz (1,500 rpm).
Does the G12V190ZLD3 run at 50 Hz or 60 Hz?
The Jichai G12V190ZLD3 is rated for 50 Hz (1,500 rpm).
What fuel does the Jichai G12V190ZLD3 use?
The Jichai G12V190ZLD3 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the G12V190ZLD3?
The Jichai G12V190ZLD3 is a V12 (12-cylinder) engine with a displacement of 71.45 L.
What emissions information is listed for the G12V190ZLD3?
This record lists China III (GB20891) for the Jichai G12V190ZLD3. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Jichai G12V190ZLD3?
The Jichai G12V190ZLD3 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
