Jichai
Jichai G12V190ZLDW-2
190 series
Jichai G12V190ZLDW-2 — 71.4 L V12 (190 × 210 mm) spark-ignited coal-mine-gas (瓦斯/CBM) generator engine (CNPC Jichai G12V190 series, genset 500GF-WK). 550 kW engine / 500 kWe at 1000 rpm / 50 Hz; external mixing with electronic AFR control for 8%–40% gas concentration, NOx ≤1200 mg/Nm³@5%O₂.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-10
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 625 kVA
- Electrical Output
- 500 kWe
- Cylinders
- V12
- Displacement
- 71.4 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 500 | 625 |
Ask about Jichai G12V190ZLDW-2
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai G12V190ZLDW-2 overhaul & repair parts
Already running a Jichai G12V190ZLDW-2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with G12V190ZLDW-2 and your selected categories included. Attach your photos there.
Jichai G12V190ZLDW-2 generator set context
The Jichai G12V190ZLDW-2 is listed here as a coal gas generator-drive engine for 50 Hz generator sets, with a headline 625 kVA / 500 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | G12V190ZLDW-2 |
| Series | 190 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 71.4 L |
| Fuel Type | Coal Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai G12V190ZLDW-2?
The Jichai G12V190ZLDW-2 is rated at 625 kVA prime at 50 Hz (1,000 rpm).
Does the G12V190ZLDW-2 run at 50 Hz or 60 Hz?
The Jichai G12V190ZLDW-2 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai G12V190ZLDW-2 use?
The Jichai G12V190ZLDW-2 is a Coal Gas generator-set engine.
What is the displacement and cylinder configuration of the G12V190ZLDW-2?
The Jichai G12V190ZLDW-2 is a V12 (12-cylinder) engine with a displacement of 71.4 L.
What is the catalog status of the Jichai G12V190ZLDW-2?
The Jichai G12V190ZLDW-2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
