Jichai
Jichai G12V190ZLDZ2-2
190 series
Jichai G12V190ZLDZ2-2 — 71.4 L V12 (190 × 210 mm) spark-ignited biogas (沼气) generator engine (CNPC Jichai G12V190 series, genset 600GF-N). 660 kW engine / 500 kWe at 1000 rpm / 50 Hz; external mixing with electronic air-fuel ratio control, adapts to varying methane content for landfill, wastewater, livestock and food-processing biogas; NOx ≤1200 mg/Nm³@5%O₂.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-10
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 625 kVA
- Electrical Output
- 500 kWe
- Cylinders
- V12
- Displacement
- 71.4 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 500 | 625 |
Ask about Jichai G12V190ZLDZ2-2
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai G12V190ZLDZ2-2 overhaul & repair parts
Already running a Jichai G12V190ZLDZ2-2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with G12V190ZLDZ2-2 and your selected categories included. Attach your photos there.
Jichai G12V190ZLDZ2-2 generator set context
The Jichai G12V190ZLDZ2-2 is listed here as a biogas generator-drive engine for 50 Hz generator sets, with a headline 625 kVA / 500 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | G12V190ZLDZ2-2 |
| Series | 190 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 71.4 L |
| Fuel Type | Biogas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai G12V190ZLDZ2-2?
The Jichai G12V190ZLDZ2-2 is rated at 625 kVA prime at 50 Hz (1,000 rpm).
Does the G12V190ZLDZ2-2 run at 50 Hz or 60 Hz?
The Jichai G12V190ZLDZ2-2 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai G12V190ZLDZ2-2 use?
The Jichai G12V190ZLDZ2-2 is a Biogas generator-set engine.
What is the displacement and cylinder configuration of the G12V190ZLDZ2-2?
The Jichai G12V190ZLDZ2-2 is a V12 (12-cylinder) engine with a displacement of 71.4 L.
What is the catalog status of the Jichai G12V190ZLDZ2-2?
The Jichai G12V190ZLDZ2-2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
