Jichai
Jichai G12V190ZLWd4-2
190 series
Jichai G12V190ZLWd4-2 — 71.4 L V12 (190 × 210 mm) spark-ignited coal-mine-gas (瓦斯/CBM) generator engine (CNPC Jichai G12V190 series, genset 600GF-Wd (400V) / 600GF9-WdK (10.5kV)). 660 kW engine / 600 kWe at 1000 rpm / 50 Hz; external mixing with electronic AFR control for 8%–40% gas concentration, NOx ≤1200 mg/Nm³@5%O₂.
- Prime Power · 50 Hz
- 750 kVA
- Electrical Output
- 600 kWe
- Cylinders
- V12
- Displacement
- 71.4 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 600 | 750 |
Technical Specifications
| Brand | Jichai |
| Model | G12V190ZLWd4-2 |
| Series | 190 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 71.4 L |
| Fuel Type | Coal Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
