Jichai
Jichai H12V190ZLD2
190 series
Jichai H12V190ZLD2 — 73.16 L V12 (190 × 215 mm) ECU common-rail turbocharged diesel generator engine (CNPC Jichai H12V190 series). 1360 kW engine / 1200 kWe genset (400 V–10.5 kV) at 1500 rpm, GB20891 Stage III, ≤202 g/kWh.
- Prime Power · 50 Hz
- 1,500 kVA
- Electrical Output
- 1,200 kWe
- Cylinders
- V12
- Displacement
- 73.16 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1200 | 1500 |
Jichai H12V190ZLD2 generator set context
The Jichai H12V190ZLD2 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 1,500 kVA / 1,200 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | H12V190ZLD2 |
| Series | 190 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 73.16 L |
| Compression Ratio | 14:1 |
| Dry Weight | 9300 kg |
| Dimensions (L×W×H) | 2950 × 1980 × 2206 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai H12V190ZLD2?
The Jichai H12V190ZLD2 is rated at 1,500 kVA prime at 50 Hz (1,500 rpm).
Does the H12V190ZLD2 run at 50 Hz or 60 Hz?
The Jichai H12V190ZLD2 is rated for 50 Hz (1,500 rpm).
What fuel does the Jichai H12V190ZLD2 use?
The Jichai H12V190ZLD2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the H12V190ZLD2?
The Jichai H12V190ZLD2 is a V12 (12-cylinder) engine with a displacement of 73.16 L.
What emissions standard does the H12V190ZLD2 meet?
The Jichai H12V190ZLD2 is certified to China III (GB20891) emissions standards.
Is the Jichai H12V190ZLD2 still in production?
Yes — the Jichai H12V190ZLD2 is a current production model.
