Jichai
Jichai H16V190ZLD
190 series
Jichai H16V190ZLD — 97.53 L V16 (190 × 215 mm) high-boost turbocharged diesel generator engine (CNPC Jichai H16V190 series). 2200 kW engine / 2000 kWe genset (400 V–10.5 kV) at 1500 rpm, GB20891 Stage III, ≤205 g/kWh.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-29
- Package route
- diesel generator sets
- Prime Power · 50 Hz
- 2,500 kVA
- Electrical Output
- 2,000 kWe
- Cylinders
- V16
- Displacement
- 97.53 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2000 | 2500 |
Ask about Jichai H16V190ZLD
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai H16V190ZLD overhaul & repair parts
Already running a Jichai H16V190ZLD? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with H16V190ZLD and your selected categories included. Attach your photos there.
Jichai H16V190ZLD generator set context
The Jichai H16V190ZLD is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,500 kVA / 2,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | H16V190ZLD |
| Series | 190 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 97.53 L |
| Compression Ratio | 14:1 |
| Dry Weight | 13000 kg |
| Dimensions (L×W×H) | 3510 × 3036 × 2344 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai H16V190ZLD?
The Jichai H16V190ZLD is rated at 2,500 kVA prime at 50 Hz (1,500 rpm).
Does the H16V190ZLD run at 50 Hz or 60 Hz?
The Jichai H16V190ZLD is rated for 50 Hz (1,500 rpm).
What fuel does the Jichai H16V190ZLD use?
The Jichai H16V190ZLD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the H16V190ZLD?
The Jichai H16V190ZLD is a V16 (16-cylinder) engine with a displacement of 97.53 L.
What emissions information is listed for the H16V190ZLD?
This record lists China III (GB20891) for the Jichai H16V190ZLD. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Jichai H16V190ZLD?
The Jichai H16V190ZLD is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
