Jichai
Jichai H16V190ZLT
190 series
Jichai H16V190ZLT — 97.53 L V16 (190 × 215 mm) spark-ignited gas generator engine (CNPC Jichai). 1100–1500 kWe at 1000 rpm; runs natural gas, biogas or coal-mine gas (CBM). CNPC's flagship engine line for oilfield and stationary power.
- Prime Power · 50 Hz
- 1,875 kVA
- Electrical Output
- 1,500 kWe
- Cylinders
- V16
- Displacement
- 97.53 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1500 | 1875 |
Technical Specifications
| Brand | Jichai |
| Model | H16V190ZLT |
| Series | 190 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 97.53 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
