Jichai
Jichai H16V190ZLWd1-2
190 series
Jichai H16V190ZLWd1-2 — 97.53 L V16 (190 × 215 mm) spark-ignited coal-mine-gas (瓦斯/CBM) generator engine (CNPC Jichai H16V190 Miller-cycle lean-burn series, genset 1000GF9-Wd (10.5kV)). 1200 kW engine / 1000 kWe at 1000 rpm / 50 Hz; low-concentration coal-mine gas, adapts to 8%–40% gas concentration, heat rate ≤10000 kJ/kWh, NOx ≤500 mg/Nm³@5%O₂.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-10
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,250 kVA
- Electrical Output
- 1,000 kWe
- Cylinders
- V16
- Displacement
- 97.53 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1000 | 1250 |
Ask about Jichai H16V190ZLWd1-2
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai H16V190ZLWd1-2 overhaul & repair parts
Already running a Jichai H16V190ZLWd1-2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with H16V190ZLWd1-2 and your selected categories included. Attach your photos there.
Jichai H16V190ZLWd1-2 generator set context
The Jichai H16V190ZLWd1-2 is listed here as a coal gas generator-drive engine for 50 Hz generator sets, with a headline 1,250 kVA / 1,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | H16V190ZLWd1-2 |
| Series | 190 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 97.53 L |
| Fuel Type | Coal Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai H16V190ZLWd1-2?
The Jichai H16V190ZLWd1-2 is rated at 1,250 kVA prime at 50 Hz (1,000 rpm).
Does the H16V190ZLWd1-2 run at 50 Hz or 60 Hz?
The Jichai H16V190ZLWd1-2 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai H16V190ZLWd1-2 use?
The Jichai H16V190ZLWd1-2 is a Coal Gas generator-set engine.
What is the displacement and cylinder configuration of the H16V190ZLWd1-2?
The Jichai H16V190ZLWd1-2 is a V16 (16-cylinder) engine with a displacement of 97.53 L.
What is the catalog status of the Jichai H16V190ZLWd1-2?
The Jichai H16V190ZLWd1-2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
