Kirloskar
6R1080T
R1080 Series
Kirloskar (KOEL) 6R1080T 6.5L 6-cylinder diesel engine for generator sets. 94 kWe standby. EPA Tier 2. kWe estimated from rated mechanical output.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 93.2 | 83.9 | 104.9 |
| Standby Power | 104.4 | 94 | 117.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 99.2 | 89.3 | 111.6 |
| Standby Power | 110.4 | 99.4 | 124.3 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Kirloskar |
| Model | 6R1080T |
| Series | R1080 Series |
| Configuration | In-line 6, Turbocharged |
| Cylinders | 6 |
| Displacement | 6.5 L |
| Fuel Type | Diesel |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | India |
