Kirloskar
6R1080TA
R1080 Series
Kirloskar (KOEL) 6R1080TA 6.5L 6-cylinder diesel engine for generator sets. 114.8 kWe standby. EPA Tier 2. kWe estimated from rated mechanical output.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 105.1 | 94.6 | 118.2 |
| Standby Power | 127.5 | 114.8 | 143.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 125.3 | 112.8 | 141 |
| Standby Power | 138 | 124.2 | 155.3 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Kirloskar |
| Model | 6R1080TA |
| Series | R1080 Series |
| Configuration | In-line 6, Turbocharged Aftercooled |
| Cylinders | 6 |
| Displacement | 6.5 L |
| Fuel Type | Diesel |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | India |
