Lovol
Lovol 1004TG
1000 Series (4cyl)
Lovol 1004TG 4.4L 4-cylinder diesel engine for generator sets. 70.4 kWe standby at 50Hz (60Hz estimated). Perkins-licensed design. Unregulated. Turbocharged.
- Standby Power · 50 Hz
- 88 kVA
- Electrical Output
- 70 kWe
- Cylinders
- L4
- Displacement
- 4.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 71.1 | 64 | 80 |
| Standby Power | 78.2 | 70.4 | 88 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 85.3 | 76.8 | 96 |
| Standby Power | 93.9 | 84.5 | 105.6 |
Lovol 1004TG generator set context
The Lovol 1004TG is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 88 kVA / 70 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Lovol |
| Model | 1004TG |
| Series | 1000 Series (4cyl) |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Lovol 1004TG?
The Lovol 1004TG is rated at 88 kVA standby / 80 kVA prime at 50 Hz (1,500 rpm); and 106 kVA standby / 96 kVA prime at 60 Hz (1,800 rpm).
Does the 1004TG run at 50 Hz or 60 Hz?
The Lovol 1004TG is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Lovol 1004TG use?
The Lovol 1004TG is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1004TG?
The Lovol 1004TG is an inline-4 (4-cylinder) engine with a displacement of 4.4 L.
Is the Lovol 1004TG still in production?
Yes — the Lovol 1004TG is a current production model.
Is a datasheet available for the 1004TG?
Yes — an official Lovol datasheet for the Lovol 1004TG can be downloaded from this page.
