Lovol
Lovol 1006TG1A
1000 Series (6cyl)
Lovol 1006TG1A 5.9L 6-cylinder diesel engine for generator sets. 96 kWe standby at 50Hz (60Hz estimated). Perkins-licensed design. Unregulated. Turbocharged.
- Standby Power · 50 Hz
- 120 kVA
- Electrical Output
- 96 kWe
- Cylinders
- L6
- Displacement
- 5.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 97.8 | 88 | 110 |
| Standby Power | 106.7 | 96 | 120 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 117.3 | 105.6 | 132 |
| Standby Power | 128 | 115.2 | 144 |
Lovol 1006TG1A generator set context
The Lovol 1006TG1A is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 120 kVA / 96 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Lovol |
| Model | 1006TG1A |
| Series | 1000 Series (6cyl) |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 5.9 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Lovol 1006TG1A?
The Lovol 1006TG1A is rated at 120 kVA standby / 110 kVA prime at 50 Hz (1,500 rpm); and 144 kVA standby / 132 kVA prime at 60 Hz (1,800 rpm).
Does the 1006TG1A run at 50 Hz or 60 Hz?
The Lovol 1006TG1A is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Lovol 1006TG1A use?
The Lovol 1006TG1A is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1006TG1A?
The Lovol 1006TG1A is an inline-6 (6-cylinder) engine with a displacement of 5.9 L.
Is the Lovol 1006TG1A still in production?
Yes — the Lovol 1006TG1A is a current production model.
Is a datasheet available for the 1006TG1A?
Yes — an official Lovol datasheet for the Lovol 1006TG1A can be downloaded from this page.
Related Engines
Compare Lovol 1006TG1A
Reference
- Canonical page
- /engines/lovol-1006tg1a
- Last database update
- 2026-06-11
- Manufacturer files
- 1 datasheet linked
