Lovol
Lovol 1106C-P6TAG4
1100 Series
Lovol 1106C-P6TAG4 7L 6-cylinder diesel engine for generator sets. 176 kWe standby at 50Hz (60Hz estimated). Perkins-licensed design. Unregulated. Turbocharged Aftercooled.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 220 kVA
- Electrical Output
- 176 kWe
- Cylinders
- L6
- Displacement
- 7 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 177.8 | 160 | 200 |
| Standby Power | 195.6 | 176 | 220 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 213.3 | 192 | 240 |
| Standby Power | 234.7 | 211.2 | 264 |
Ask about Lovol 1106C-P6TAG4
Choose parts / service or sourcing. Your message includes this model and page link.
Lovol 1106C-P6TAG4 overhaul & repair parts
Already running a Lovol 1106C-P6TAG4? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 1106C-P6TAG4 and your selected categories included. Attach your photos there.
Lovol 1106C-P6TAG4 generator set context
The Lovol 1106C-P6TAG4 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 220 kVA / 176 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Lovol |
| Model | 1106C-P6TAG4 |
| Series | 1100 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Lovol 1106C-P6TAG4?
The Lovol 1106C-P6TAG4 is rated at 220 kVA standby / 200 kVA prime at 50 Hz (1,500 rpm); and 264 kVA standby / 240 kVA prime at 60 Hz (1,800 rpm).
Does the 1106C-P6TAG4 run at 50 Hz or 60 Hz?
The Lovol 1106C-P6TAG4 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Lovol 1106C-P6TAG4 use?
The Lovol 1106C-P6TAG4 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1106C-P6TAG4?
The Lovol 1106C-P6TAG4 is an inline-6 (6-cylinder) engine with a displacement of 7 L.
What is the catalog status of the Lovol 1106C-P6TAG4?
The Lovol 1106C-P6TAG4 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 1106C-P6TAG4?
This page links reference documents for the Lovol 1106C-P6TAG4. Check each document's title, model coverage, revision and rating conditions before using it for selection.
