Mesa
Mesa GV22PU
PowerCore
Mesa GV22PU — 21.9 L V12 (128 × 142 mm, 2 valves/cyl) EPA-certified spark-ignited natural-gas / propane generator engine, built on a Hyundai block. Up to 450 kW standby (60 Hz) / 399 kW (50 Hz); engine output 510 kW (684 hp) at 60 Hz.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-11
- Package route
- gas generator sets
- Standby Power · 50 Hz
- 499 kVA
- Electrical Output
- 399 kWe
- Cylinders
- V12
- Displacement
- 21.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | — | 399 | 498.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 409 | 511.4 |
| Standby Power | — | 450 | 562.5 |
Ask about Mesa GV22PU
Choose parts / service or sourcing. Your message includes this model and page link.
Mesa GV22PU overhaul & repair parts
Already running a Mesa GV22PU? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with GV22PU and your selected categories included. Attach your photos there.
Mesa GV22PU generator set context
The Mesa GV22PU is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 499 kVA / 399 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mesa |
| Model | GV22PU |
| Series | PowerCore |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 21.9 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | EPA |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Mesa GV22PU?
The Mesa GV22PU is rated at 499 kVA standby at 50 Hz (1,500 rpm); and 563 kVA standby / 511 kVA prime at 60 Hz (1,800 rpm).
Does the GV22PU run at 50 Hz or 60 Hz?
The Mesa GV22PU is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Mesa GV22PU use?
The Mesa GV22PU is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the GV22PU?
The Mesa GV22PU is a V12 (12-cylinder) engine with a displacement of 21.9 L.
What emissions information is listed for the GV22PU?
This record lists U.S. EPA Stationary for the Mesa GV22PU. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Mesa GV22PU?
The Mesa GV22PU is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the GV22PU?
This page links reference documents for the Mesa GV22PU. Check each document's title, model coverage, revision and rating conditions before using it for selection.
