Mesa
Mesa GX22
PowerCore
Mesa GX22 — 21.9 L V12 (128 × 142 mm, 4 valves/cyl, ~20% more power) EPA-certified spark-ignited natural-gas / propane generator engine, built on a Hyundai block. Up to 540 kW standby (60 Hz) / 478 kW (50 Hz); engine output 612 kW (684 hp) at 60 Hz.
- Standby Power · 50 Hz
- 598 kVA
- Electrical Output
- 478 kWe
- Cylinders
- V12
- Displacement
- 21.9 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | — | 478 | 597.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 491 | 613.6 |
| Standby Power | — | 540 | 675 |
Mesa GX22 generator set context
The Mesa GX22 is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 598 kVA / 478 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mesa |
| Model | GX22 |
| Series | PowerCore |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 21.9 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | EPA |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Mesa GX22?
The Mesa GX22 is rated at 598 kVA standby at 50 Hz (1,500 rpm); and 675 kVA standby / 614 kVA prime at 60 Hz (1,800 rpm).
Does the GX22 run at 50 Hz or 60 Hz?
The Mesa GX22 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Mesa GX22 use?
The Mesa GX22 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the GX22?
The Mesa GX22 is a V12 (12-cylinder) engine with a displacement of 21.9 L.
What emissions standard does the GX22 meet?
The Mesa GX22 is certified to U.S. EPA Stationary emissions standards.
Is the Mesa GX22 still in production?
Yes — the Mesa GX22 is a current production model.
Is a datasheet available for the GX22?
Yes — an official Mesa datasheet for the Mesa GX22 can be downloaded from this page.
