Mitsubishi
Mitsubishi S12R-PTAA2
S12R Series
Mitsubishi S12R-PTAA2 49.03L 12-cylinder diesel engine for generator sets. 1314 kW prime power. Unregulated. Turbocharged, Intercooled.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,621 kVA
- Electrical Output
- 1,297 kWe
- Cylinders
- V12
- Displacement
- 49.03 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1314 | 1182.6 | 1478.2 |
| Standby Power | 1441 | 1296.9 | 1621.1 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1484 | 1335.6 | 1669.5 |
| Standby Power | 1633 | 1469.7 | 1837.1 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S12R-PTAA2
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S12R-PTAA2 overhaul & repair parts
Already running a Mitsubishi S12R-PTAA2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Reviewed part-number references
A starting point for identification. Fitment must be confirmed before ordering.
- Turbocharger49182-03890
Turbocharger assembly
Fitment check: Match the exact MTEA Engine Type label S12R-PTAA2; use the complete engine serial number and current MEeS illustration to select among all listed turbocharger numbers before ordering
Source: Mitsubishi Turbocharger and Engine America official catalog - 49182-03890-Turbocharger
Selected references only; this is not a complete overhaul list or a stock listing.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S12R-PTAA2 and your selected categories included. Attach your photos there.
Mitsubishi S12R-PTAA2 generator set context
The Mitsubishi S12R-PTAA2 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,621 kVA / 1,297 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S12R-PTAA2 |
| Series | S12R Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 49.03 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S12R-PTAA2?
The Mitsubishi S12R-PTAA2 is rated at 1,621 kVA standby / 1,478 kVA prime at 50 Hz (1,500 rpm); and 1,837 kVA standby / 1,670 kVA prime at 60 Hz (1,800 rpm).
Does the S12R-PTAA2 run at 50 Hz or 60 Hz?
The Mitsubishi S12R-PTAA2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Mitsubishi S12R-PTAA2 use?
The Mitsubishi S12R-PTAA2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S12R-PTAA2?
The Mitsubishi S12R-PTAA2 is a V12 (12-cylinder) engine with a displacement of 49.03 L.
What is the catalog status of the Mitsubishi S12R-PTAA2?
The Mitsubishi S12R-PTAA2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S12R-PTAA2?
This page links reference documents for the Mitsubishi S12R-PTAA2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
