Mitsubishi S16R-PTAA2
Mitsubishi S16R-PTAA2 65.37L 16-cylinder diesel engine for generator sets. 1760 kW prime power. Unregulated. Turbocharged, Intercooled.
Production StatusIn Production
S16R Series
- Configuration
- V16
- Displacement
- 65.37 L
- Fuel
- Diesel
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| Rating | Prime | Standby |
|---|---|---|
| Mechanical power kWm | 1,760 | 1,939 |
| Electrical output kWe | 1,584 | 1,745.1 |
| Apparent power kVA | 1,980 | 2,181.4 |
60 Hz1800 RPM
| Rating | Prime | Standby |
|---|---|---|
| Mechanical power kWm | 1,939 | 2,149 |
| Electrical output kWe | 1,745.1 | 1,934.1 |
| Apparent power kVA | 2,181.4 | 2,417.6 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Mitsubishi |
| Model | S16R-PTAA2 |
| Series | S16R Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 65.37 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Check your engine model
The Mitsubishi S16R-PTAA2 is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 2,181 kVA / 1,745 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
s16rptaa2S16R PTAA2Mitsubishi S16R-PTAA2S16R Series S16R-PTAA2
S16R-PTAA2 repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Other parts? Add them in the chat.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Part-number references
Confirm fitment against your engine serial number.
- Turbocharger49182-04923
Fitment details & source
Turbocharger assembly
Fitment check: Match the exact MTEA Engine Type label S16R-PTAA2; use the complete engine serial number and current MEeS illustration to select among all listed turbocharger numbers before ordering
Source: Mitsubishi Turbocharger and Engine America official catalog - 49182-04923-Turbocharger
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
What is the power output of the Mitsubishi S16R-PTAA2?
The Mitsubishi S16R-PTAA2 is rated at 2,181 kVA standby / 1,980 kVA prime at 50 Hz (1,500 rpm); and 2,418 kVA standby / 2,181 kVA prime at 60 Hz (1,800 rpm).
Does the S16R-PTAA2 run at 50 Hz or 60 Hz?
The Mitsubishi S16R-PTAA2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Mitsubishi S16R-PTAA2 use?
The Mitsubishi S16R-PTAA2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S16R-PTAA2?
The Mitsubishi S16R-PTAA2 is a V16 (16-cylinder) engine with a displacement of 65.37 L.
What is the catalog status of the Mitsubishi S16R-PTAA2?
The Mitsubishi S16R-PTAA2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S16R-PTAA2?
This page links reference documents for the Mitsubishi S16R-PTAA2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
