Mitsubishi
Mitsubishi S16R-PTAR-C
S16R Series
Mitsubishi S16R-PTAR-C 65.37L 16-cylinder Shanghai MHI generator-drive diesel engine. 1617 kWm prime and 1779 kWm standby at 50 Hz/1500 rpm.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,113 kVA
- Electrical Output
- 1,690 kWe
- Cylinders
- V16
- Displacement
- 65.37 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1617 | 1536.1 | 1920.1 |
| Standby Power | 1779 | 1690.1 | 2112.6 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S16R-PTAR-C
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S16R-PTAR-C overhaul & repair parts
Already running a Mitsubishi S16R-PTAR-C? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S16R-PTAR-C and your selected categories included. Attach your photos there.
Mitsubishi S16R-PTAR-C generator set context
The Mitsubishi S16R-PTAR-C is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,113 kVA / 1,690 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S16R-PTAR-C |
| Series | S16R Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 65.37 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Mitsubishi S16R-PTAR-C?
The Mitsubishi S16R-PTAR-C is rated at 2,113 kVA standby / 1,920 kVA prime at 50 Hz (1,500 rpm).
Does the S16R-PTAR-C run at 50 Hz or 60 Hz?
The Mitsubishi S16R-PTAR-C is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S16R-PTAR-C use?
The Mitsubishi S16R-PTAR-C is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S16R-PTAR-C?
The Mitsubishi S16R-PTAR-C is a V16 (16-cylinder) engine with a displacement of 65.37 L.
What is the catalog status of the Mitsubishi S16R-PTAR-C?
The Mitsubishi S16R-PTAR-C is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S16R-PTAR-C?
This page links reference documents for the Mitsubishi S16R-PTAR-C. Check each document's title, model coverage, revision and rating conditions before using it for selection.
