Mitsubishi
Mitsubishi S16R-Y2PTAW2
S16R Series
Mitsubishi S16R-Y2PTAW2 65.370L V16 constant-speed diesel engine for generator applications. Official MHI output without fan - 60 Hz: prime 1982 kWm at 1800 rpm, standby 2180 kWm at 1800 rpm. Emissions: Unregulated (prime); U.S. EPA Tier 2 (standby).
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 2,589 kVA
- Electrical Output
- 2,071 kWe
- Cylinders
- V16
- Displacement
- 65.37 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1982 | 1883.2 | 2354 |
| Standby Power | 2180 | 2071.2 | 2589 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S16R-Y2PTAW2
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S16R-Y2PTAW2 overhaul & repair parts
Already running a Mitsubishi S16R-Y2PTAW2? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S16R-Y2PTAW2 and your selected categories included. Attach your photos there.
Mitsubishi S16R-Y2PTAW2 generator set context
The Mitsubishi S16R-Y2PTAW2 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 2,589 kVA / 2,071 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S16R-Y2PTAW2 |
| Series | S16R Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 65.37 L |
| Dry Weight | 6680 kg |
| Dimensions (L×W×H) | 3046 × 1457 × 1810 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S16R-Y2PTAW2?
The Mitsubishi S16R-Y2PTAW2 is rated at 2,589 kVA standby / 2,354 kVA prime at 60 Hz (1,800 rpm).
Does the S16R-Y2PTAW2 run at 50 Hz or 60 Hz?
The Mitsubishi S16R-Y2PTAW2 is rated for 60 Hz (1,800 rpm).
What fuel does the Mitsubishi S16R-Y2PTAW2 use?
The Mitsubishi S16R-Y2PTAW2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S16R-Y2PTAW2?
The Mitsubishi S16R-Y2PTAW2 is a V16 (16-cylinder) engine with a displacement of 65.37 L.
What emissions information is listed for the S16R-Y2PTAW2?
This record lists U.S. EPA Tier 2 for the Mitsubishi S16R-Y2PTAW2. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Mitsubishi S16R-Y2PTAW2?
The Mitsubishi S16R-Y2PTAW2 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S16R-Y2PTAW2?
This page links reference documents for the Mitsubishi S16R-Y2PTAW2. Check each document's title, model coverage, revision and rating conditions before using it for selection.
