Mitsubishi
Mitsubishi S4L2-T61SD
S4L2 Series
Mitsubishi S4L2-T61SD 1.758L L4 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: standby 17.7 kWm at 1500 rpm. Emissions: Unregulated.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-07-23
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 19 kVA
- Electrical Output
- 15 kWe
- Cylinders
- L4
- Displacement
- 1.758 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 17.7 | 15 | 18.8 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Ask about Mitsubishi S4L2-T61SD
Choose parts / service or sourcing. Your message includes this model and page link.
Mitsubishi S4L2-T61SD overhaul & repair parts
Already running a Mitsubishi S4L2-T61SD? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with S4L2-T61SD and your selected categories included. Attach your photos there.
Mitsubishi S4L2-T61SD generator set context
The Mitsubishi S4L2-T61SD is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 19 kVA / 15 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S4L2-T61SD |
| Series | S4L2 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 1.758 L |
| Dry Weight | 170 kg |
| Dimensions (L×W×H) | 678 × 444 × 640 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S4L2-T61SD?
The Mitsubishi S4L2-T61SD is rated at 19 kVA standby at 50 Hz (1,500 rpm).
Does the S4L2-T61SD run at 50 Hz or 60 Hz?
The Mitsubishi S4L2-T61SD is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S4L2-T61SD use?
The Mitsubishi S4L2-T61SD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S4L2-T61SD?
The Mitsubishi S4L2-T61SD is an inline-4 (4-cylinder) engine with a displacement of 1.758 L.
What is the catalog status of the Mitsubishi S4L2-T61SD?
The Mitsubishi S4L2-T61SD is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S4L2-T61SD?
This page links reference documents for the Mitsubishi S4L2-T61SD. Check each document's title, model coverage, revision and rating conditions before using it for selection.
