Mitsubishi S4L2-Z562SD
Mitsubishi S4L2-Z562SD 1.758L L4 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 14 kWm at 1485 rpm, standby 15.4 kWm at 1485 rpm. Emissions: Euro Stage V.
Production StatusIn Production
S4L2 Series
- Configuration
- L4
- Displacement
- 1.758 L
- Fuel
- Diesel
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1485 RPM
| Rating | Prime | Standby |
|---|---|---|
| Mechanical power kWm | 14 | 15.4 |
| Electrical output kWe | 11.9 | 13.1 |
| Apparent power kVA | 14.9 | 16.4 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | Mitsubishi |
| Model | S4L2-Z562SD |
| Series | S4L2 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 1.758 L |
| Dry Weight | 160 kg |
| Dimensions (L×W×H) | 678 × 442 × 572 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | Japan |
Check your engine model
The Mitsubishi S4L2-Z562SD is a diesel generator-drive engine for 50 Hz generator sets, rated at 16 kVA / 13 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
s4l2z562sdS4L2 Z562SDMitsubishi S4L2-Z562SDS4L2 Series S4L2-Z562SD
S4L2-Z562SD repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Parts reference availability
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
What is the power output of the Mitsubishi S4L2-Z562SD?
The Mitsubishi S4L2-Z562SD is rated at 16 kVA standby / 15 kVA prime at 50 Hz (1,485 rpm).
Does the S4L2-Z562SD run at 50 Hz or 60 Hz?
The Mitsubishi S4L2-Z562SD is rated for 50 Hz (1,485 rpm).
What fuel does the Mitsubishi S4L2-Z562SD use?
The Mitsubishi S4L2-Z562SD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S4L2-Z562SD?
The Mitsubishi S4L2-Z562SD is an inline-4 (4-cylinder) engine with a displacement of 1.758 L.
What emissions information is listed for the S4L2-Z562SD?
This record lists Euro Stage V for the Mitsubishi S4L2-Z562SD. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Mitsubishi S4L2-Z562SD?
The Mitsubishi S4L2-Z562SD is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the S4L2-Z562SD?
This page links reference documents for the Mitsubishi S4L2-Z562SD. Check each document's title, model coverage, revision and rating conditions before using it for selection.
