MTU
MTU 12V1600 G01S
Series 1600 Gx1
MTU 12V1600 G01S 22.4 L V12 diesel/HVO gendrive engine with a 126 x 150 mm bore and stroke, rated at 664 kWm gross mechanical power at 1800 RPM for 60 Hz data center continuous service. MTU lists the Series 1600 Gx1 with an EPA Tier 2 calibration. Electrical kWe and kVA depend on the selected generator package and alternator and are not inferred here.
- Electrical Output
- 664 kW
- Cylinders
- V12
- Displacement
- 22.444 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 664 | — | — |
MTU 12V1600 G01S generator set context
The MTU 12V1600 G01S is listed here as a diesel/hvo generator-drive engine for 60 Hz generator sets, with a headline 664 kW / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | 12V1600 G01S |
| Series | Series 1600 Gx1 |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 22.444 L |
| Fuel Type | Diesel/HVO |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Certifications | U.S. EPA Tier 2 |
| Country of Origin | Germany |
| Year Introduced | 2024 |
Frequently asked questions
What is the power output of the MTU 12V1600 G01S?
The MTU 12V1600 G01S is rated at 830 kVA prime at 60 Hz (1,800 rpm).
Does the 12V1600 G01S run at 50 Hz or 60 Hz?
The MTU 12V1600 G01S is rated for 60 Hz (1,800 rpm).
What fuel does the MTU 12V1600 G01S use?
The MTU 12V1600 G01S is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12V1600 G01S?
The MTU 12V1600 G01S is a V12 (12-cylinder) engine with a displacement of 22.444 L.
What emissions standard does the 12V1600 G01S meet?
The MTU 12V1600 G01S is certified to U.S. EPA Tier 2 emissions standards.
Is the MTU 12V1600 G01S still in production?
Yes — the MTU 12V1600 G01S is a current production model.
Is a datasheet available for the 12V1600 G01S?
Yes — an official MTU datasheet for the MTU 12V1600 G01S can be downloaded from this page.
