MTU 12V1600 G11S
MTU 12V1600 G11S 22.4 L V12 diesel/HVO gendrive engine with a 126 x 150 mm bore and stroke, rated at 712 kWm gross mechanical power at 1800 RPM for 60 Hz data center continuous service. MTU lists the Series 1600 Gx1 with an EPA Tier 2 calibration. Electrical kWe and kVA depend on the selected generator package and alternator and are not inferred here.
Production StatusIn Production
Series 1600 Gx1
- Mechanical Output
- 712 kW
- Cylinders
- V12
- Displacement
- 22.444 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| Rating | Prime |
|---|---|
| Mechanical power kWm | 712 |
Estimated electrical output
Engine power × 0.90. These are estimates, not manufacturer generator ratings. Actual output depends on the alternator and operating conditions.
| Frequency / duty | Engine | Estimate |
|---|---|---|
| 60 HzPrime | 712 kWm | 640.8 kWe |
Datasheet & documents
Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.
Technical specifications
Technical Specifications
| Brand | MTU |
| Model | 12V1600 G11S |
| Series | Series 1600 Gx1 |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 22.444 L |
| Fuel Type | Diesel/HVO |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Certifications | U.S. EPA Tier 2 |
| Country of Origin | Germany |
| Year Introduced | 2024 |
Check your engine model
The MTU 12V1600 G11S is a diesel/hvo generator-drive engine for 60 Hz generator sets, rated at 712 kW / prime rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.
Other ways this model is written
12v1600g11sMTU 12V1600 G11SSeries 1600 Gx1 12V1600 G11S
12V1600 G11S repair parts
Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.
Get a parts & air-shipping quoteIn-stock parts: same-day dispatch
Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.
Find the right part
Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.
Get my parts quote on WhatsAppWe’ll confirm the correct parts, stock and delivery cost before you order.
Opens WhatsApp. Attach photos in the chat.
Photos and details to send
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Parts reference availability
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Get help with this engine
Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.
Other ways to contact us
Scan QRHide QR
General WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales teamNeed help after checking the documents?
Send us the part number or describe the problem. This engine model is included in your message.
Send this model enquiry by emailOr browse Haifeng's diesel generator sets
Frequently asked questions
Does the 12V1600 G11S run at 50 Hz or 60 Hz?
The MTU 12V1600 G11S is rated for 60 Hz (1,800 rpm).
What fuel does the MTU 12V1600 G11S use?
The MTU 12V1600 G11S is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12V1600 G11S?
The MTU 12V1600 G11S is a V12 (12-cylinder) engine with a displacement of 22.444 L.
What emissions information is listed for the 12V1600 G11S?
This record lists U.S. EPA Tier 2 for the MTU 12V1600 G11S. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the MTU 12V1600 G11S?
The MTU 12V1600 G11S is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 12V1600 G11S?
This page links reference documents for the MTU 12V1600 G11S. Check each document's title, model coverage, revision and rating conditions before using it for selection.
