MTU
MTU 8V1600G20S 3B
Series 1600
MTU 8V1600G20S 3B 14.028 L V8 Turbocharged diesel engine for 60 Hz generator applications. The 2024 EPA record certifies 408 kWm at 1800 RPM. U.S. EPA Tier 3.
- Electrical Output
- 408 kW
- Cylinders
- V8
- Displacement
- 14.028 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 408 | — | — |
MTU 8V1600G20S 3B generator set context
The MTU 8V1600G20S 3B is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 408 kW / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | 8V1600G20S 3B |
| Series | Series 1600 |
| Configuration | V8 Turbocharged |
| Cylinders | 8 |
| Displacement | 14.028 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 3 |
| Certifications | U.S. EPA Tier 3 |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU 8V1600G20S 3B?
The MTU 8V1600G20S 3B is rated at 510 kVA prime at 60 Hz (1,800 rpm).
Does the 8V1600G20S 3B run at 50 Hz or 60 Hz?
The MTU 8V1600G20S 3B is rated for 60 Hz (1,800 rpm).
What fuel does the MTU 8V1600G20S 3B use?
The MTU 8V1600G20S 3B is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 8V1600G20S 3B?
The MTU 8V1600G20S 3B is a V8 (8-cylinder) engine with a displacement of 14.028 L.
What emissions standard does the 8V1600G20S 3B meet?
The MTU 8V1600G20S 3B is certified to U.S. EPA Tier 3 emissions standards.
Is the MTU 8V1600G20S 3B still in production?
Yes — the MTU 8V1600G20S 3B is a current production model.
Reference
- Canonical page
- /engines/mtu-8v1600g20s-3b
- Last database update
- 2026-07-25
- Manufacturer files
- No datasheet linked yet
