MTU
MTU 8V4000 GS
Series 4000
MTU 8V4000 GS — 38.2 L V8 (170 × 210 mm) lean-burn spark-ignited natural-gas GenDrive engine (mtu Series 4000). 776–1012 kWe across L32/L33/L64 ratings at 1500 rpm / 50 Hz, electrical efficiency up to ~44%; NOx < 500 mg/Nm³.
- Prime Power · 50 Hz
- 1,265 kVA
- Electrical Output
- 1,012 kWe
- Cylinders
- V8
- Displacement
- 38.2 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1012 | 1265 |
MTU 8V4000 GS generator set context
The MTU 8V4000 GS is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 1,265 kVA / 1,012 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | 8V4000 GS |
| Series | Series 4000 |
| Configuration | V8 |
| Cylinders | 8 |
| Displacement | 38.2 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MTU 8V4000 GS?
The MTU 8V4000 GS is rated at 1,265 kVA prime at 50 Hz (1,500 rpm).
Does the 8V4000 GS run at 50 Hz or 60 Hz?
The MTU 8V4000 GS is rated for 50 Hz (1,500 rpm).
What fuel does the MTU 8V4000 GS use?
The MTU 8V4000 GS is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the 8V4000 GS?
The MTU 8V4000 GS is a V8 (8-cylinder) engine with a displacement of 38.2 L.
Is the MTU 8V4000 GS still in production?
Yes — the MTU 8V4000 GS is a current production model.
