Perkins
Perkins 1106A-70TAG3
1100 Series
The Perkins 1106A-70TAG3 is a 7-litre inline-6 diesel engine for generator sets, rated at 200 kVA / 160 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Chat on WhatsApp about this engine
Opens WhatsApp with Perkins 1106A-70TAG3 and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 200 kVA
- Electrical Output
- 160 kWe
- Cylinders
- L6
- Displacement
- 7 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 160 | 144 | 180 |
| Standby Power | 177.8 | 160 | 200 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 175.6 | 158 | 197.5 |
| Standby Power | 194.4 | 175 | 218.8 |
Perkins 1106A-70TAG3 generator set context
The Perkins 1106A-70TAG3 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 200 kVA / 160 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 1106A-70TAG3 |
| Series | 1100 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Perkins 1106A-70TAG3?
The Perkins 1106A-70TAG3 is rated at 200 kVA standby / 180 kVA prime at 50 Hz (1,500 rpm); and 219 kVA standby / 198 kVA prime at 60 Hz (1,800 rpm).
Does the 1106A-70TAG3 run at 50 Hz or 60 Hz?
The Perkins 1106A-70TAG3 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 1106A-70TAG3 use?
The Perkins 1106A-70TAG3 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1106A-70TAG3?
The Perkins 1106A-70TAG3 is an inline-6 (6-cylinder) engine with a displacement of 7 L.
Is the Perkins 1106A-70TAG3 still in production?
Yes — the Perkins 1106A-70TAG3 is a current production model.
Is a datasheet available for the 1106A-70TAG3?
Yes — an official Perkins datasheet for the Perkins 1106A-70TAG3 can be downloaded from this page.
