Perkins
Perkins 1106A-70TG1
1100 Series
The Perkins 1106A-70TG1 is a 7-litre inline-6 diesel engine for generator sets, rated at 150 kVA / 120 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 150 kVA
- Electrical Output
- 120 kWe
- Cylinders
- L6
- Displacement
- 7 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 120 | 108 | 135 |
| Standby Power | 133.3 | 120 | 150 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 135.6 | 122 | 152.5 |
| Standby Power | 150 | 135 | 168.8 |
Technical Specifications
| Brand | Perkins |
| Model | 1106A-70TG1 |
| Series | 1100 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Perkins 1106A-70TG1?
The Perkins 1106A-70TG1 is rated at 150 kVA standby / 135 kVA prime at 50 Hz (1,500 rpm); and 169 kVA standby / 153 kVA prime at 60 Hz (1,800 rpm).
Does the 1106A-70TG1 run at 50 Hz or 60 Hz?
The Perkins 1106A-70TG1 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 1106A-70TG1 use?
The Perkins 1106A-70TG1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1106A-70TG1?
The Perkins 1106A-70TG1 is an inline-6 (6-cylinder) engine with a displacement of 7 L.
Is the Perkins 1106A-70TG1 still in production?
Yes — the Perkins 1106A-70TG1 is a current production model.
Is a datasheet available for the 1106A-70TG1?
Yes — an official Perkins datasheet for the Perkins 1106A-70TG1 can be downloaded from this page.
