Perkins
Perkins 1106D-E70TAG2
1100 Series
Perkins 1106D-E70TAG2 7.01 L L6 ElectropaK diesel engine for generator sets. At 60 Hz and 1800 RPM, Perkins publishes 145 kWm net / 130 kWe prime and 161 kWm net / 143 kWe standby. Euro Stage IIIA / U.S. EPA Tier 3.
Chat on WhatsApp about this engine
Opens WhatsApp with Perkins 1106D-E70TAG2 and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 163 kVA
- Electrical Output
- 130 kWe
- Cylinders
- L6
- Displacement
- 7.01 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 130 | 117 | 146.3 |
| Standby Power | 144.4 | 130 | 162.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 145 | 130 | 162 |
| Standby Power | 161 | 143 | 178 |
Perkins 1106D-E70TAG2 generator set context
The Perkins 1106D-E70TAG2 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 163 kVA / 130 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 1106D-E70TAG2 |
| Series | 1100 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.01 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage IIIA / U.S. EPA Tier 3 |
| Certifications | Euro Stage IIIA, U.S. EPA Tier 3 |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 1106D-E70TAG2?
The Perkins 1106D-E70TAG2 is rated at 163 kVA standby / 146 kVA prime at 50 Hz (1,500 rpm); and 178 kVA standby / 162 kVA prime at 60 Hz (1,800 rpm).
Does the 1106D-E70TAG2 run at 50 Hz or 60 Hz?
The Perkins 1106D-E70TAG2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 1106D-E70TAG2 use?
The Perkins 1106D-E70TAG2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1106D-E70TAG2?
The Perkins 1106D-E70TAG2 is an inline-6 (6-cylinder) engine with a displacement of 7.01 L.
What emissions standard does the 1106D-E70TAG2 meet?
The Perkins 1106D-E70TAG2 is certified to Euro Stage IIIA / U.S. EPA Tier 3 emissions standards.
Is the Perkins 1106D-E70TAG2 still in production?
Yes — the Perkins 1106D-E70TAG2 is a current production model.
Is a datasheet available for the 1106D-E70TAG2?
Yes — an official Perkins datasheet for the Perkins 1106D-E70TAG2 can be downloaded from this page.
