Perkins
Perkins 1106D-E70TAG5
1100 Series
Perkins 1106D-E70TAG5 7.01 L L6 ElectropaK diesel engine for generator sets. At 60 Hz and 1800 RPM, Perkins publishes 203 kWm net / 182 kWe prime and 224 kWm net / 200 kWe standby. Euro Stage IIIA / U.S. EPA Tier 3.
Chat on WhatsApp about this engine
Opens WhatsApp with Perkins 1106D-E70TAG5 and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-07-25
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 250 kVA
- Electrical Output
- 200 kWe
- Cylinders
- L6
- Displacement
- 7.01 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 203 | 182 | 227 |
| Standby Power | 224 | 200 | 250 |
Perkins 1106D-E70TAG5 generator set context
The Perkins 1106D-E70TAG5 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 250 kVA / 200 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 1106D-E70TAG5 |
| Series | 1100 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.01 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage IIIA / U.S. EPA Tier 3 |
| Certifications | Euro Stage IIIA, U.S. EPA Tier 3 |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 1106D-E70TAG5?
The Perkins 1106D-E70TAG5 is rated at 250 kVA standby / 227 kVA prime at 60 Hz (1,800 rpm).
Does the 1106D-E70TAG5 run at 50 Hz or 60 Hz?
The Perkins 1106D-E70TAG5 is rated for 60 Hz (1,800 rpm).
What fuel does the Perkins 1106D-E70TAG5 use?
The Perkins 1106D-E70TAG5 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 1106D-E70TAG5?
The Perkins 1106D-E70TAG5 is an inline-6 (6-cylinder) engine with a displacement of 7.01 L.
What emissions standard does the 1106D-E70TAG5 meet?
The Perkins 1106D-E70TAG5 is certified to Euro Stage IIIA / U.S. EPA Tier 3 emissions standards.
Is the Perkins 1106D-E70TAG5 still in production?
Yes — the Perkins 1106D-E70TAG5 is a current production model.
Is a datasheet available for the 1106D-E70TAG5?
Yes — an official Perkins datasheet for the Perkins 1106D-E70TAG5 can be downloaded from this page.
