Perkins
Perkins 4012-46TAG2A
4000 Series
The Perkins 4012-46TAG2A is a 46-litre V12 diesel engine for generator sets, rated at 1,650 kVA / 1,320 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United Kingdom.
Overhaul & repair parts- Supporting documents
- 3 documents · 3 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 1,650 kVA
- Electrical Output
- 1,320 kWe
- Cylinders
- V12
- Displacement
- 46 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1333.3 | 1200 | 1500 |
| Standby Power | 1466.7 | 1320 | 1650 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 1342.2 | 1208 | 1510 |
| Standby Power | 1476.7 | 1329 | 1661.3 |
Ask about Perkins 4012-46TAG2A
Choose parts / service or sourcing. Your message includes this model and page link.
Perkins 4012-46TAG2A overhaul & repair parts
Already running a Perkins 4012-46TAG2A? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 4012-46TAG2A and your selected categories included. Attach your photos there.
Perkins 4012-46TAG2A generator set context
The Perkins 4012-46TAG2A is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 1,650 kVA / 1,320 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 4012-46TAG2A |
| Series | 4000 Series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 46 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 4012-46TAG2A?
The Perkins 4012-46TAG2A is rated at 1,650 kVA standby / 1,500 kVA prime at 50 Hz (1,500 rpm); and 1,661 kVA standby / 1,510 kVA prime at 60 Hz (1,800 rpm).
Does the 4012-46TAG2A run at 50 Hz or 60 Hz?
The Perkins 4012-46TAG2A is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 4012-46TAG2A use?
The Perkins 4012-46TAG2A is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4012-46TAG2A?
The Perkins 4012-46TAG2A is a V12 (12-cylinder) engine with a displacement of 46 L.
What is the catalog status of the Perkins 4012-46TAG2A?
The Perkins 4012-46TAG2A is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4012-46TAG2A?
This page links reference documents for the Perkins 4012-46TAG2A. Check each document's title, model coverage, revision and rating conditions before using it for selection.
