Perkins
Perkins 4006-23TAG2A
4000 Series
The Perkins 4006-23TAG2A is a 23-litre V6 diesel engine for generator sets, rated at 820 kVA / 656 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United Kingdom.
Chat on WhatsApp about this engine
Opens WhatsApp with Perkins 4006-23TAG2A and this page link filled in.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 820 kVA
- Electrical Output
- 656 kWe
- Cylinders
- V6
- Displacement
- 23 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 663.3 | 597 | 746.3 |
| Standby Power | 728.9 | 656 | 820 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 666.7 | 600 | 750 |
| Standby Power | 733.3 | 660 | 825 |
Perkins 4006-23TAG2A generator set context
The Perkins 4006-23TAG2A is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 820 kVA / 656 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 4006-23TAG2A |
| Series | 4000 Series |
| Configuration | V6 |
| Cylinders | 6 |
| Displacement | 23 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 4006-23TAG2A?
The Perkins 4006-23TAG2A is rated at 820 kVA standby / 746 kVA prime at 50 Hz (1,500 rpm); and 825 kVA standby / 750 kVA prime at 60 Hz (1,800 rpm).
Does the 4006-23TAG2A run at 50 Hz or 60 Hz?
The Perkins 4006-23TAG2A is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 4006-23TAG2A use?
The Perkins 4006-23TAG2A is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4006-23TAG2A?
The Perkins 4006-23TAG2A is a V6 (6-cylinder) engine with a displacement of 23 L.
Is the Perkins 4006-23TAG2A still in production?
Yes — the Perkins 4006-23TAG2A is a current production model.
Is a datasheet available for the 4006-23TAG2A?
Yes — an official Perkins datasheet for the Perkins 4006-23TAG2A can be downloaded from this page.
