PSI
PSI 2.4L T
PSI 2.4L T — 2.35 L L4 (86.5 × 100 mm bore × stroke) turbocharged & air-cooled natural gas / propane generator engine, 9.5:1 compression, 136 kg dry. From the official PSI 2.4L T spec sheet (60 Hz rated; LPG standby 40 kWe).
- Standby Power · 60 Hz
- 50 kVA
- Electrical Output
- 40 kWe
- Cylinders
- L4
- Displacement
- 2.35 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 50 | 40 | 50 |
PSI 2.4L T generator set context
The PSI 2.4L T is listed here as a natural gas generator-drive engine for 60 Hz generator sets, with a headline 50 kVA / 40 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | PSI |
| Model | 2.4L T |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.35 L |
| Compression Ratio | 9.5:1 |
| Dry Weight | 136 kg |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | EPA |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the PSI 2.4L T?
The PSI 2.4L T is rated at 50 kVA standby at 60 Hz (1,800 rpm).
Does the 2.4L T run at 50 Hz or 60 Hz?
The PSI 2.4L T is rated for 60 Hz (1,800 rpm).
What fuel does the PSI 2.4L T use?
The PSI 2.4L T is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the 2.4L T?
The PSI 2.4L T is an inline-4 (4-cylinder) engine with a displacement of 2.35 L.
What emissions standard does the 2.4L T meet?
The PSI 2.4L T is certified to U.S. EPA Stationary emissions standards.
Is the PSI 2.4L T still in production?
Yes — the PSI 2.4L T is a current production model.
Is a datasheet available for the 2.4L T?
Yes — an official PSI datasheet for the PSI 2.4L T can be downloaded from this page.
