SDEC
SDEC 16KTA76-G34
K Series
The SDEC 16KTA76-G34 is a 76-litre V16 diesel engine for generator sets, rated at 2,486 kVA / 1,989 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Supporting documents
- No documents linked
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 2,486 kVA
- Electrical Output
- 1,989 kWe
- Cylinders
- V16
- Displacement
- 76 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2010 | 1809 | 2261.3 |
| Standby Power | 2210 | 1989 | 2486.3 |
Ask about SDEC 16KTA76-G34
Choose parts / service or sourcing. Your message includes this model and page link.
SDEC 16KTA76-G34 overhaul & repair parts
Already running a SDEC 16KTA76-G34? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 16KTA76-G34 and your selected categories included. Attach your photos there.
SDEC 16KTA76-G34 generator set context
The SDEC 16KTA76-G34 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 2,486 kVA / 1,989 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | SDEC |
| Model | 16KTA76-G34 |
| Series | K Series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 76 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the SDEC 16KTA76-G34?
The SDEC 16KTA76-G34 is rated at 2,486 kVA standby / 2,261 kVA prime at 50 Hz (1,500 rpm).
Does the 16KTA76-G34 run at 50 Hz or 60 Hz?
The SDEC 16KTA76-G34 is rated for 50 Hz (1,500 rpm).
What fuel does the SDEC 16KTA76-G34 use?
The SDEC 16KTA76-G34 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 16KTA76-G34?
The SDEC 16KTA76-G34 is a V16 (16-cylinder) engine with a displacement of 76 L.
What is the catalog status of the SDEC 16KTA76-G34?
The SDEC 16KTA76-G34 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
