SDEC
SDEC SC4H115D2
H Series
SDEC SC4H115D2 4L 4-cylinder diesel engine for generator sets. 78 kWm prime / 86 kWm standby at 50Hz/1500RPM.
- Standby Power · 50 Hz
- 96 kVA
- Electrical Output
- 77 kWe
- Cylinders
- L4
- Displacement
- 4 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 78 | 70 | 87.5 |
| Standby Power | 86 | 77 | 96.3 |
SDEC SC4H115D2 generator set context
The SDEC SC4H115D2 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 96 kVA / 77 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | SDEC |
| Model | SC4H115D2 |
| Series | H Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage II / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the SDEC SC4H115D2?
The SDEC SC4H115D2 is rated at 96 kVA standby / 88 kVA prime at 50 Hz (1,500 rpm).
Does the SC4H115D2 run at 50 Hz or 60 Hz?
The SDEC SC4H115D2 is rated for 50 Hz (1,500 rpm).
What fuel does the SDEC SC4H115D2 use?
The SDEC SC4H115D2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the SC4H115D2?
The SDEC SC4H115D2 is an inline-4 (4-cylinder) engine with a displacement of 4 L.
Is the SDEC SC4H115D2 still in production?
Yes — the SDEC SC4H115D2 is a current production model.
