VMAN
VMAN C04B
The VMAN C04B is a 4.3-litre inline-4 diesel engine for generator sets, rated at 149 kVA / 119 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-08
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 149 kVA
- Electrical Output
- 119 kWe
- Cylinders
- L4
- Displacement
- 4.3 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 120 | 108 | 135 |
| Standby Power | 132 | 119 | 148.8 |
Ask about VMAN C04B
Choose parts / service or sourcing. Your message includes this model and page link.
VMAN C04B overhaul & repair parts
Already running a VMAN C04B? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with C04B and your selected categories included. Attach your photos there.
VMAN C04B generator set context
The VMAN C04B is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 149 kVA / 119 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | VMAN |
| Model | C04B |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the VMAN C04B?
The VMAN C04B is rated at 149 kVA standby / 135 kVA prime at 60 Hz (1,800 rpm).
Does the C04B run at 50 Hz or 60 Hz?
The VMAN C04B is rated for 60 Hz (1,800 rpm).
What fuel does the VMAN C04B use?
The VMAN C04B is a diesel generator-set engine.
What is the displacement and cylinder configuration of the C04B?
The VMAN C04B is an inline-4 (4-cylinder) engine with a displacement of 4.3 L.
What is the catalog status of the VMAN C04B?
The VMAN C04B is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the C04B?
This page links reference documents for the VMAN C04B. Check each document's title, model coverage, revision and rating conditions before using it for selection.
